Do you need a custom size Lally Column? Our Lally Columns are 4 inches in diameter and made of 11 gauge steel. * All loads listed are with adjustable screw extended completely and encased in concrete.
Just tell us the height or length you need and we can get started today!
We ship Lally Columns in all sizes every day, Coast to Coast!
Maximum Load Ratings Compared
Load Rating Chart for custom Lally Columns
Model #
Adj. Length
(in.)Column Weight
(lb.)Maximum Load
(lb.)
LA 459 (-)
1’0” - 5’11”
N/A
28,900
AC460
6’0” - 6’4”
37.8
28,900
AC463
6’3” - 6’7”
39.0
28,500
AC466
6’6” - 6’10”
40.3
28,100
AC469
6’9” - 7’1”
41.5
27,600
AC470
7’0” - 7’4”
42.8
27,200
AC473
7’3” - 7’7”
44.0
26,800
AC476 View Here
7’6” - 7’10”
45.3
26,300
AC479 View Here
7’9” - 8’1”
46.5
25,800
AC480
8’0” - 8’4”
47.8
25,300
AC483
8’3” - 8’7”
49.0
24,800
AC486
8’6” - 8’10”
50.3
24,400
AC489
8’9” - 9’1”
51.5
23,900
AC490
9’0” - 9’4”
52.8
23,400
AC493
9’3” - 9’7”
54.0
23,000
AC496
9’6” - 9’10”
55.3
22,400
AC499
9’9” - 10’1”
56.5
21,900
AC4100
10’0” - 10’4”
57.8
21,400
AC24000
10'5 - 24 feet
(Call Us)
(Call Us)
Column Specifications
(The International Residential Code and International Building Code).
4” x 8” plate welded to top end.
3-1/2” x 6” plate permanently attached to screw assembly for bottom end.
